CODE:ASME SECT.VIII DIV.1 2023 EDITION

Code Certification:ASME U stamp or ASME UM stamp or PED certified

Operating Pressure : -1-19MPa

Design Pressure :-1-20MPa

Temperature: -20-150ºC

Minimum design metal temperature(MDMT) at MAWP:-20ºC at 1MPa

Hydrostatic test pressure:1.43MPa at 0-48ºC

Medium name:compressed air

Corrosion allowance:1mm

Gross volume:0.001-100m³

Empty weight:5-20000kg
